Diatone MAMBA TOKA 2207.5 1700 2450KV 4-6S Motor

Item: Diatone MAMBA TOKA 2207.5 1700KV 2450KV Brushless Motor
Parameters:

TOKA 2207.5 1700KV

Motor model: 2207.5
KV value: 1700
Weight: 36g
Dimensions: Φ28.5×32.65mm
Propeller fixed shaft diameter: M5
Mounting hole position: 16×16mm, M3
Applicable blade: 5inch~6inch
Bearing size: 4*9*4
Shaft diameter: 4mm
Outlet specification: 24AWG ×190mm
Configuration: 12N14P
Enameled Wire: Class H, 220℃ Enameled Wire
Stator diameter: 22mm
Stator thickness: 7.5mm
Rated voltage: 4~6S (16.8V~25.2V)
Peak current: 38.5A
Maximum power: 924W

TOKA 2207.5 2450KV
Motor model: 2207.5
KV value: 2450
Weight: 35g
Dimensions: Φ28.5×32.65mm
Propeller fixed shaft diameter: M5
Mounting hole position: 16×16mm, M3
Applicable blade: 5inch~6inch
Bearing size: 4*9*4
Shaft diameter: 4mm
Outlet specification: 24AWG ×190mm
Configuration: 12N14P
Enameled Wire: Class H, 220℃ Enameled Wire
Stator diameter: 22mm
Stator thickness: 7.5mm
Rated voltage: 3~4S (12.6V~16.8V)
Peak current: 44.1A
Maximum power: 706W
