DIATONE MAMBA TOKA 2203.5 2650KV3300KV Brushless Motor

MAMBA TOKA 2203.5 2650KV Motor

Overall Dimension:Φ28.9×29.4mm

prop mounting shaft diameter:5mm

Installation hole position:16×16mm,M3

Prop: 5inch

Bearing:9*4*4

Shaft Diameter:4.0mm

Lead Wire Size:24AWG×190mm

slots/poles:12N14P

Magnet Wire: 240℃ Enameled Wire

Stator Diamter:22mm

Stator Height:3.5mm

Pated Voltage:3~4S (12.6V~16.8V)

Peak Current: 27.64A

ldle Current:10V/0.9~1.9A

Maximum Power: 441.24W

Internal Resistance:120mΩ

Mamba Toka 2203.5 3300KV Motor

Overall Dimension:Φ28.9×29.4mm

Prop mounting shaft diameter:5mm

Installation hole position:16×16mm,M3

Prop: 3.5inch

Bearing:9*4*4

Shaft Diameter:4.0mm

Lead Wire Size:24AWG×190mm

slots/poles:12N14P

Magnet Wire: 240℃ Enameled Wire

Stator Diamter:22mm

Stator Height:3.5mm

Rated Voltage:3~4S (12.6V~16.8V)

Peak Current: 29.78A

ldle Current:10V/1.5~2.2A

Maximum Power: 475.1W

Internal Resistance:80mΩ
