FLASHHOBBY KING K2306.5 Brushless Motor

FLASHHOBBY KING K2306.5 Brushless Motor

Check out  all our 2306 motors and the rest of FlashHobby Motors.

K2306.5 RC Brushless Motor Specification
Max pull：1617g（6S/GF6040 3R）
Volts：DC16~25.0 V/Li-Po(4-6S)
No Load Current/Maximum Load Curren：1.01A/23.89A
No Load Speed(RPM）：0~1900PRM/1v
Maximum Power：705.9W

K2306.5-2300KV Motor Specification
Max pull：1577g（4S/GF6040 3R）
Volts：DC12~24V/Li-Po(3-4S）
No Load Current/Maximum Load Curren：1.79A/34.21A
No Load Speed(RPM）：0~2300PRM/1v
Maximum Power：695.5W

K2306.5-2550KV Motor Specification
Max pull：1406g（4S/GF60403R ）
Volts：DC12~16.8 V/ Li-Po(3-4S）
No Load Current/Maximum Load Curren：1.65A/32.86A
No Load Speed(RPM）：0~2550PRM/1v
Maximum Power： 531.3W

Working Temperature Range：-0℃~+80℃<br>
Control Method：Use ESC And Adjust PWM signal For Control，PWM Adjustment Range 900- 2100US<br>
Motor Type: Outrunner Brushless Motor,Three-phase Motor<br>

MOTOR Drawing:
